D7024 | Operation and Installation Guide | 2.0 Overview
Bosch | 7/05 | 31499J 13
Ta b l e 7 summarizes address restrictions for the D7042, D7052, and D7053 Modules.
Table 7: D7042 Address Restrictions
9* 10 11 12 13 14 15 16
17 * 18 19 20 21 22 23 24
25* 26 27 28 29 30 31 32
33* 34 35 36 37 38 39 40
41*42434445464748
49* 50 51 52 53 54 55 56
57*58596061626364
65* 66 67 68 69 70 71 72
73*74757677787980
81* 82 83 84 85 86 87 88
89*90919293949596
97* 98 99 100 101 102 103 104
105* 106 107 108 109 110 111 112
113 * 114 115 116 117 118 119 120
121* 122 123 124 125 126 127 128
129* 130 131 132 13 3 134 135 136
137* 138 139 140 141 142 143 144
145 * 146 147 14 8 149 150 151 152
153* 154 155 156 157 158 15 9 160
161* 162 163 164 16 5 166 167 168
16 9 * 17 0 171 17 2 17 3 174 17 5 176
17 7 * 17 8 17 9 180 181 182 183 184
185* 186 187 188 18 9 190 191 192
193* 194 195 196 197 198 19 9 200
201* 202 203 204 205 206 207 208
209* 210 211 212 213 214 215 216
217* 218 219 220 221 222 223 224
225* 226 227 228 229 230 231 232
233* 234 235 236 237 238 239 240
241* 242 243 244 245 246 247 248
249 250 251 252 253 254 255
Note: Install the D7042 Modules only at addresses that are followed by an asterisk (*). Do not install the D7052 and D7053
Modules (Class “B”) on addresses in bold.
