Brother HL-1200 Service Manual

1-13
Confidential
3.3 Error Messages for Maintenance Printing
(Refer to "5. MAINTENANCE PRINTING" in chapter 4.)
Refer to the page shown in the “Refer to:” column in the table below to take appropriate
measures when the following error messages are displayed on maintenance printing.
Error Message Refer to:
CARTRIDGE ERROR 4.4.2, 4.4.3
COOLING DOWN 4.7.5
DRUM ! DRUM ERROR 4.4.4, 4.4.5
DRUM END SOON 4.4.6
ERROR E51 (LASER BD MALF) 4.6.1
ERROR E52 (SCANNER MALF) 4.6.1
ERROR E54 (MOTOR MALF) 4.7.7
ERROR E55 (HIGH VOL MALF) 4.7.9
ERROR H63 (DRAM ERROR) 4.4.4, 4.4.5
ERROR H66 (NV-W ERROR) 4.7.4
ERROR H67 (NV-R ERROR) 4.7.4
ERROR H68 (NV-B ERROR) 4.7.4
ERROR H75 (ZEROCROSS ERROR) 4.7.8
ERROR S01 (MAIN PCB ERROR) 4.7.10
JAM INSIDE 1 4.1.4
JAM INSIDE 2 4.1.4
JAM INSIDE 3 4.1.4
JAM TRAY 4.1.4
MEMORY FULL 4.7.4
NO DRUM 4.4.5
NO PAPER 4.1.1
NO TONER 4.4.2
PRINT UNABLE ZC (ZEROCROSS ERROR) 4.7.8
REPLACE DRUM 4.4.5
REPLACE TONER 4.4.1
TONER ENDED 4.4.6
TONER LOW 4.4.1
TOP COVER OPEN 4.7.2
WRONG PAPER TYPE 4.7.6

Brother HL-1200 Specifications

General

Print Technology	Laser
Interface	USB 2.0
Memory	1 MB
Weight	4.6 kg
Print Speed	20 ppm
Resolution	Up to 2400 x 600 dpi
Paper Input Capacity	150 sheets
Dimensions	340 mm x 238 mm x 189 mm
Supported Operating Systems	Windows, Mac OS
