Brother HL-1200 Service Manual

2-9
Confidential
7.2 Back cover
(1) Remove the two taptite bind B M4x12 screws.
(2) Release the two hooks at the top of the back cover while lifting it.
(3) Slide the back cover downward to remove the two bosses at the bottom.
Fig. 2-4
Back cover
Bosses
Hooks
Taptite bind B
M4x12

Brother HL-1200 Specifications

General

Print Technology	Laser
Interface	USB 2.0
Memory	1 MB
Weight	4.6 kg
Print Speed	20 ppm
Resolution	Up to 2400 x 600 dpi
Paper Input Capacity	150 sheets
Dimensions	340 mm x 238 mm x 189 mm
Supported Operating Systems	Windows, Mac OS
