Brother HL-1200 Service Manual

2-2
Confidential
2. TIGHTENING TORQUE LISTS
Location of screw Part name Q'ty
Tightening torque
N·m (kgf·cm)
Back cover Taptite bind B M4x12 2 0.8±0.1(8±1)
Low voltage shield plate cover
Taptite bind B M4x12 4 0.8±0.1(8±1)
Taptite cup S M3x8 SR 2 0.6±0.1(6±1)
Screw pan
(S/P washer) M3.5x6
10.45±0.05(4.55±0.5)
Ground harness
Screw pan
(S/P washer) M3.5x6
10.45±0.05(4.55±0.5)
Fuser unit Taptite pan B M4x14 2 0.8±0.1(8±1)
Insulation roof Taptite pan B M3x8 1 0.4±0.05(4±0.5)
High voltage power supply PCB ASSY Taptite bind B M4x12 2 0.8±0.1(8±1)
Main PCB ASSY Taptite cup S M3x6 SR
2
0.6±0.1(6±1)
Ground harness 1
Front cover Taptite bind B M4x12 4 0.8±0.1(8±1)
Laser unit Taptite cup S M3x8 SR 3 0.8±0.1(8±1)
Paper feed/paper printing position
sensor PCB ASSY
Taptite bind B M3x10 1 0.5±0.1(5±1)
Drive sub ASSY Taptite bind B M4x12 4 0.8±0.1(8±1)

Brother HL-1200 Specifications

General

Print Technology	Laser
Interface	USB 2.0
Memory	1 MB
Weight	4.6 kg
Print Speed	20 ppm
Resolution	Up to 2400 x 600 dpi
Paper Input Capacity	150 sheets
Dimensions	340 mm x 238 mm x 189 mm
Supported Operating Systems	Windows, Mac OS
