Cisco cBR 8 Configuration Guide

duration 30 avg-rate 1 sample-interval 10 upstream enforce
enabled
Example: Downstream and Upstream Configuration
The following example shows a typical enforce-rule configuration for traffic in both the downstream and
upstream directions. Two separate rules are created, using the identical configuration, except for the keywords
upstream and downstream in the duration command.
The enforce rules for the upstream and downstream directions can use either an identical configuration,
or they can use their own individual configurations.
Note
!
cable qos enforce-rule upstream-rule
monitoring-basics legacy docsis11
penalty-period 10
service-class registered class5
service-class enforced class99
duration 30 avg-rate 5 sample-interval 10 upstream enforce
enabled
cable qos enforce-rule downstream-rule
monitoring-basics legacy docsis11
penalty-period 10
service-class registered class5
service-class enforced class99
duration 30 avg-rate 5 sample-interval 10 downstream enforce
enabled
The following example shows an enforce-rule configuration for traffic in upstream direction. A unique penalty
duration is configured for upstream, with monitoring turned on after the penalty release time.
For upstream direction, a unique penalty duration (120 minutes) is configured, which takes precedence
over the duration configured using the penalty-period command (60 minutes). A fresh monitoring starts
after the penalty release time (23:00), when all the traffic counters are reset to 0.
Note
!
cable qos enforce-rule upstream_rule
monitoring-basics peak-offpeak docsis10
penalty-period 60 time-of-day 23:00 monitoring-on
qos-profile registered 6
qos-profile enforced 100
peak-time1 10:30 duration 120 avg-rate 10 peak-time2 22:10 duration 60 avg-rate 10
sample-interval 10 penalty 120 upstream enforce
enabled
Example: Weekend Monitoring Configuration
The following example shows a sample configuration of peak-offpeak weekend monitoring for DOCSIS 1.0
cable modems:
cable qos enforce-rule monitoring
monitoring-basics peak-offpeak docsis10
penalty-period 60
qos-profile registered 6
qos-profile enforced 100
Cisco cBR Series Converged Broadband Routers Quality of Services Configuration Guide for Cisco IOS XE Fuji
16.7.x
141
Subscriber Traffic Management
Example: Downstream and Upstream Configuration
