Monitoring BPI+ Operations
See the following sections to monitor the state of BPI operations on the CMTS and its connected cable modems:
Displaying the Current BPI+ State of Cable Modems
To display the current BPI+ state of cable modems, use the show cable modem command. If used without
any options, this command displays the status for cable modems on all interfaces. You can also specify a
particular cable interface on the CMTS, or the IP address or MAC address for a specific cable modem:
Router# show cable modem
[ip-address
| interface
| mac-address
The MAC State column in the output of the show cable modem command displays the current status of each
cable modem. The following are the possible BPI-related values for this field:
Table 13: Possible show cable modem BPI+ States
DescriptionState
A cable modem has come online and, if configured
to use BPI+, is negotiating its privacy parameters for
the session. If the modem remains in this state for
more than a couple of minutes, it is online but not
using BPI+. Check that the cable modem is running
DOCSIS-certified software and is using a DOCSIS
configuration file that enables BPI+.
online
The cable modem is online and has negotiated a Key
Encryption Key(KEK) with the CMTS. If BPI+
negotiation is successful, this state will be shortly
followed by online(pt).
online(pk)
The cable modem is online and has negotiated a
Traffic Encryption Key (TEK) with the CMTS. The
BPI+ session has been established, and the cable
modem is encrypting all user traffic with the CMTS
using the specified privacy parameters.
online(pt)
Cisco cBR Series Converged Broadband Routers Quality of Services Configuration Guide for Cisco IOS XE
Fuji 16.7.x
66
DOCSIS 1.1 for the Cisco CMTS Routers
Monitoring BPI+ Operations
