SpecificationDescription
8.5 lb (3.86 kg)Weight
Supervisor-1 Module Specifications
The following table lists the specifications for the Cisco MDS 9700 Supervisor-1 Modules.
Table 27: Cisco MDS 9700 Supervisor-1 Module Specifications
SpecificationDescription
Environmental Requirements
32 to 104°F (0 to 40°C)
Temperature, certified for operation (module intake
of ambient)
-40 to 158°F (-40 to 70°C)Temperature, ambient nonoperating and storage
8 to 80%Humidity (RH), ambient (noncondensing) operating
0 to 6500 ft (0 to 2000 m)Altitude, certified for operation
-197 to 6500 ft (-60 to 2000 m)Altitude, designed and tested for operation
Physical Characteristics
2.04 x 7.5 x 21.8 in. (5.18 x 19.05 x 55.37 cm)
Dimensions
7 lb (3.2 kg)Weight
Crossbar Fabric Switching Module Specifications
The following table lists the specifications for the Cisco MDS 9700 Series Crossbar Fabric Switching Modules.
Table 28: Cisco MDS 9700 Series Crossbar Fabric Switching Module Specifications
SpecificationDescription
Environmental Requirements
32 to 104°F (0 to 40°C)
Temperature, certified for operation (module intake
of ambient)
-40 to 158°F (-40 to 70°C)Temperature, ambient nonoperating and storage
10 to 90%Humidity (RH), ambient (noncondensing) operating
0 to 6500 ft (0 to 2000 m)Altitude, certified for operation
-197 to 6500 ft (-60 to 2000 m)Altitude, designed and tested for operation
Physical Characteristics
Cisco MDS 9700 Series Switches Hardware Installation Guide
184
Technical Specifications
Supervisor-1 Module Specifications
