Handles used for adjusting the chassis placement4
Vertical mounting brackets5
System LEDs
The following table describes the system LEDs for the Cisco MDS 9700 Series.
Table 2: Cisco MDS 9700 Series System LEDs
DescriptionStatusLED
Power supply units are operational.GreenPower supply unit
One of the following problems has occurred:
• Any power supply unit LED is red.
• Any power supply unit is down.
Amber
Fan modules are operational.
GreenFan module
At least one I/O module has the red STATUS LED.Amber
Supervisor modules are operational.
GreenSupervisor modules
At least one I/O module has the red STATUS LED.Amber
Crossbar fabric switching modules are operational.
GreenCrossbar fabric switching modules
At least one I/O module has the red STATUS LED.Amber
Switching modules are operational.
GreenI/O modules
At least one I/O module has the red STATUS LED.Amber
Supervisor Modules
This section describes supervisor modules that are supported by different Cisco MDS 9700 Series switches.
The supervisor modules are:
Cisco MDS 9700 Series Supervisor-4 Module
The Cisco MDS 9700 Series Supervisor-4 Module (DS-X97-SF4-K9) provides control and management
functions for the Cisco MDS Director switches and enables intelligent, resilient, scalable, and high-performance
multilayer SAN switching.
The Cisco MDS 9700 Series Supervisor-4 Module (DS-X97-SF4-K9) is supported on the Cisco MDS 9706
and 9710 Multilayer Directors from Cisco MDS NX-OS Release 8.4(1) or later. It is supported on the Cisco
MDS 9718 Multilayer Director from Cisco MDS NX-OS Release 8.4(2a) or later.
The Cisco MDS 9700 Series Supervisor-4 Module supports the following features:
Cisco MDS 9700 Series Switches Hardware Installation Guide
21
Product Overview
System LEDs
