Cisco MDS 9700 Series User Manual

Fiber Channel port group. A port group
consists of 16 ports.
8Status LED4
The following table describes the LEDs for the 48-Port 32-Gbps Fiber Channel Switching Module.
Table 10: Cisco MDS 48-Port 32-Gbps Fiber Channel Switching Module LEDs
DescriptionStatusLED
All diagnostics pass. The module is operational (normal initialization
sequence).
GreenStatus
One of the following occurs or occurred:
• The module is booting or running diagnostics (normal initialization
sequence).
• An over temperature condition has occurred. (A minor temperature
threshold has been exceeded during environmental monitoring.)
Orange
One of the following occurs:
• The module is resetting. The switch has been powered on or the
module has been hot inserted during the normal initialization
sequence.
• An over temperature condition has occurred. (A major temperature
threshold has been exceeded during environmental monitoring.)
• If the module fails to download code and configuration information
successfully during the initial reset, the LED stays blinking red;
the module does not come online.
Blinking Red
The module has detected a slot ID parity error on the mid plane. The
module cannot determine its slot number and will not respond to the
supervisor.
Solid Red
The module is not receiving power.Off
The operator has activated this LED to identify this module in the chassis.
Blinking blueID
This module is not selected.Off
The port is active (the link is connected and operational).
GreenLink
SFP is not present or Admin is down.Solid Orange
A fault condition exists.Blinking Orange
The port is not active or the link is not connected.Off
Cisco MDS 48-Port 16-Gbps Fiber Channel Switching Module
The Cisco MDS 9700 48-Port 16-Gbps Switching Module is designed specifically for the Cisco MDS 9700
Series Director Switches. These modules are hot-swappable and compatible with 2, 4, 8, 10, and 16-Gbps
interfaces, and they support hot-swappable Enhanced Small Form-Factor Pluggable (SFP+) transceivers.
Cisco MDS 9700 Series Switches Hardware Installation Guide
44
Product Overview
Cisco MDS 48-Port 16-Gbps Fiber Channel Switching Module
