Cisco MDS 9700 Series User Manual

DescriptionStatusLED
The mgmt0 interface is administratively active when the supervisor is in the HA-active state.
GreenMGMT0 Ethernet
From Cisco MDS NX-OS Release 8.4(2), when the supervisor is in HA-standby state, the mgmt0 interface
is not administratively active.
On Cisco MDS NX-OS Release 8.4(1a) or earlier, when the supervisor is in the HA-standby state, the
mgmt0 interface is not administratively active.
Amber
The management port link is bad and has been disabled due to a hardware failure.Blinking amber
The mgmt0 interface is uninitialized. No signal is detected.Off
Frames are being transmitted or received by the interface.
Blinking GreenACT
There is no activity on the interface.Off
The management port link is operational.
GreenLink
No link signal received.Off
The log flash CompactFlash or USB disk is being accessed. Do not remove the media until the LED is
off.
GreenLOG FLASH
The expansion flash CompactFlash or USB disk is not being accessed. You can remove the media while
this LED is off.
Off
The log flash CompactFlash or USB disk is being accessed. Do not remove the media until the LED is
off.
GreenSlot0
The expansion flash CompactFlash or USB disk is not being accessed. You can remove the media while
this LED is off.
Off
Cisco MDS 9700 Series Supervisor-1 Module
The Cisco MDS 9700 Series Supervisor-1 Module (DS-X97-SF1-K9) provides control and management
functions for the Director switches and enables high-performance switching.
The Cisco MDS 9700 Series Supervisor-1 Module (DS-X97-SF1-K9) is designed specifically for the Cisco
MDS 9706 and 9710 chassis.
The Cisco MDS 9700 Series Supervisor-1 Module supports the following features:
• Supports up to 384 2/4/8/10/16/32-Gbps Fiber Channel ports, or 1/10-Gbps FCoE ports in a single Cisco
MDS 9710 Multilayer Director chassis
• Supports up to 192 2/4/8/10/16/32-Gbps Fiber Channel ports, or 1/10-Gbps FCoE ports in a single Cisco
MDS 9706 Multilayer Director chassis
• Supports up to 192 40-Gbps FCoE ports in a single Cisco MDS 9710 Multilayer Director chassis
• Supports up to 96 40-Gbps FCoE ports in a single Cisco MDS 9706 Multilayer Director chassis
• Up to 24 terabits per second (Tbps) in a single Cisco MDS 9710 Multilayer Director chassis
• Up to 12 terabits per second (Tbps) in a single Cisco MDS 9706 Multilayer Director chassis
• Supports DS-X9710-FAB1 and DS-X9706-FAB1 crossbar fabric switching module on the Cisco MDS
9710 and 9706 Multilayer Directors respectively
