Cisco MDS 9700 Series User Manual

This unit is intended for installation in restricted access areas. A restricted access area can be accessed only
through the use of a special tool, lock and key, or other means of security. Statement 1017
Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning
Before you install, operate, or service the system, see the Regulatory Compliance and Safety Information for
the Cisco MDS 9000 Family for important safety information.
Note
Step 1 Verify that the rack-mount support brackets are level and securely attached to the rack-mounting rails, the support
rack-mount support brace is securely attached to the brackets, and the rack is stabilized.
Step 2 Slide a mechanical lift under the switch and lift the switch up onto the rack-mount support brackets, ensuring it is squarely
positioned.
Step 3 Attach the switch to the rack-mounting rails. See the
We recommend grounding the chassis, even if the rack is already grounded. There is a grounding pad with
two threaded M4 holes on the chassis for attaching a grounding lug.
Caution
Installing the Switch on the Shelf Brackets
This section provides general instructions for installing the switch on top of the shelf brackets. For detailed
installation instructions for the shelf brackets, see the Installing the Cisco MDS 9700 Series Shelf Bracket
Kit into a Rack, on page 71 procedure.
Before you begin
The Cisco MDS 9700 Series Shelf Bracket Kit can be used to support the switch in a nonthreaded rack. This
shelf bracket kit can be used as a permanent support when installing a Cisco MDS 9700 Series Director in a
rack that meets the requirements listed in the Rack and Cabinet Requirements, on page 66 section.
This unit is intended for installation in restricted access areas. A restricted access area can be accessed only
through the use of a special tool, lock and key, or other means of security. Statement 1017
Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning
Before you install, operate, or service the system, see the Regulatory Compliance and Safety Information for
the Cisco MDS 9000 Family for important safety information.
Note
Cisco MDS 9700 Series Switches Hardware Installation Guide
73
Preparing the Site
Installing the Switch on the Shelf Brackets
