Table 47: Console Port Pinouts
SignalPin
RTS1
4
DTR2
TxD3
GND4
GND5
RxD6
DSR7
CTS8
4
Pin 1 is connected internally to pin 8.
Connecting the Console Port to a Computer Using the DB-25 Adapter
You can use the RJ-45 rollover cable and RJ-45/DSUB F/F adapter (labeled “Terminal”) to connect the console
port to a computer running terminal emulation software. The following table lists the pinouts for the console
port, the RJ-45 rollover cable, and the RJ-45/DSUB F/F adapter.
Table 48: Port Mode Signaling and Pinouts with the DB-25 Adapter
Console DeviceRJ4-5/DSUB F/F
Terminal Adapter
RJ-45 Rollover CableConsole Port
SignalDB-25 PinRJ-45 PinRJ-45 PinSignal
CTS581RTS
DSR672DTR
RxD363TxD
GND754GND
GND745GND
TxD236RxD
DTR2027DSR
RTS418CTS
MGMT 10/100/1000 Ethernet Port
The MGMT 10/100/1000 Ethernet port is an Ethernet port with an RJ-45 connector. You can use a modular,
RJ-45, straight-through UTP cable to connect the management port to an external hub, switch, or router as
described in the following figure.
Cisco MDS 9700 Series Switches Hardware Installation Guide
198
Cable and Port Specifications
Connecting the Console Port to a Computer Using the DB-25 Adapter
