Configuring Virtual Private Networks (VPNs) and Security
Configuring Advanced VPN Parameters
Cisco RV180/RV180W Administration Guide 119
5
Configuring VPN Users
Use the VPN > IPsec > VPN Users page to configure PPTP Server settings (if
applicable) and to add VPN clients for PPTP, XAUTH, and Cisco QuickVPN.
NOTE You can also created comma-separated value (CSV) files containing user
information and import them to easily add multiple users. See Importing CSV Files,
page 149.
VPN clients must be configured with the same VPN policy parameters used in the
VPN tunnel that the client wishes to use: encryption, authentication, lifetime, and
PFS key-group. Upon establishing these authentication parameters, the VPN client
user database must also be populated with an account to give a user access to
the tunnel. The VPN gateway authenticates users in this list when XAUTH is used
in an IKE policy.
VPN client software is required to establish a VPN tunnel between the router and
remote endpoint. Open source software (such as OpenVPN or Openswan) as well
as Microsoft IPsec VPN software can be configured with the required IKE policy
parameters to establish an IPsec VPN tunnel. Refer to the client software guide for
detailed instructions on setup as well as the router’s online help.
To open this page: In the navigation tree, choose VPN > IPsec > VPN Users.
STEP 1 If you are using a Point-to-Point Tunneling Protocol VPN server, enter these
settings in the PPTP Server Configuration section:
• PPTP Server—Check the Enable box to enable this feature, or uncheck the
box to disable it.
• Starting IP Address—Enter the starting IP address of the range of IP
addresses for the PPTP VPN tunnel.
• Ending IP Address—Enter the ending IP address of the range of IP
addresses for the PPTP VPN tunnel. The range can include up to 10
addresses.
Note: The starting IP of the PPTP client IP range is used as the PPTP server
IP of the router and the remaining PPTP client IP address range is used to
assign IP address to PPTP clients. If the address range is within a VLAN
range, the PPTP clients are members of that VLAN. Access to other VLANs
Action Choose Connect to establish a connection, or Drop
to terminate an established connection.
