Administering Your Cisco RV180/RV180W
Upgrading Firmware
Cisco RV180/RV180W Administration Guide 152
7
Sample CSV file format:
"5","domain1","SSLVPN","radius_pap","14.0.0.1","test","","",""
"4","group2","domain1","30"
"3","cisco","RWUSER","1","SHA","authPassword","AES","privPassword"
"2","p2","pp2"
"1","rrrr","sss","0","1"
"0","user102","sss","dddd","SSLVPN","4","10","0","1","0","0","fail"
Importing a File
Use the Administration > CSV File Import page to import a CSV file that you
created for domains, groups, and users.
STEP 1 Click Browse.
STEP 2 On your computer, locate and select the .csv file. Click Import.
Upgrading Firmware
CAUTION During a firmware upgrade, do not try to go online, turn off the device, shut down
the PC, or interrupt the process in any way until the operation is complete. This
process takes about a minute, including the reboot process. Interrupting the
upgrade process at specific points when the flash is being written to may corrupt
the flash memory and render the router unusable.
You can upgrade to a newer firmware version from the Administration > Firmware
Upgrade page. To upgrade:
STEP 1 Click Browse, locate and select the downloaded firmware, and click Upload.
STEP 2 (Optional) Check the box to reset all configuration and settings to the default
values. Do not check this box if you want to keep any settings you have changed
on the router!
STEP 3 Click Start Firmware Upgrade. After the new firmware image is validated, the new
image is written to flash, and the router is automatically rebooted with the new
