Configuring SNMP
Configuring SNMP Views
Cisco Small Business 300 Series Managed Switch Administration Guide 283
19
STEP 4 Enter the parameters.
• View Name—Enter a view name.
• Object ID Subtree—Select the node in the MIB tree that is included or
excluded in the selected SNMP view. The options to select the object are as
follows:
- Select from List—Enables you to navigate the MIB tree. Press the Up
arrow to go to the level of the selected node's father and siblings; press
the Down arrow to descend to the level of the selected node's
descendents. Click nodes in the view to pass from one node to its brother.
Use the scrollbar to bring siblings in view.
- User defined—Enter an OID not offered in the Select from List option (if
required). All descendents of this node are included or excluded in the
view.
STEP 5 Select or deselect Include in view.
• If Select from list is used, the Object Identifier of the selected node is
included in or excluded from the view if the Include in view option is
selected or not selected.
• If User defined is used, the entered Object Identifier is included in or
excluded from the view if the Include in view option is selected or not
selected.
STEP 6 Click Apply. If you used
Select from list,
the object identifier of the selected node
is included in or excluded from the view as determined by the Include in view
option is selected.
If you used Object ID, the entered object identifier is included in or excluded from
the view if the Include in view option is selected. This means that the node and its
descendents are included or excluded from the view. The SNMP views are
defined, and the switch is updated.
