GENERAL
GENERAL SPECIFICATION: LIFTING AND SUPPORTING THE VEHICLE
Front of the vehicle.
The authorised lifting points at the front of the vehicle are on the rear fixing bolts of the
subframe at «a».
For front lifting, take weight at the two lifting points at «a», using a crossbeam equipped
with blocks.
For front lifting from the side, take weight at the lifting point at «a».
ESSENTIAL: Never attempt to lift by the front panel mountings.
Side lifting.
Always ensure the jack is correctly positioned
at the lifting points.
Do not place the axle stands under the jack
contact lugs.
Positioning of the axle stand.
E2AP016C
E2AP00GC
E2AP017C
Side lifting
Front lifting
C4AP1GWC
Lifting and supporting the vehicle
E2AP018C
