234
ENGINES
OIL PRESSURE CHECKS
Petrol Diesel
Engine type KFU NFU RFJ RFN RFK 9HX 9HY 9HZ RHR
Temperature (°C) 90° 80°
Pressure (Bars) 1,5 3 1,3 1,9
RPM 1000
Pressure (Bars) 3 5,6 4
RPM 2000 2000 2000
Pressure (Bars) 5 6,3
RPM 3000 3000
Pressure (Bars) 4 3,5
RPM 4000 4000
Tools (Toolkit 4103)
2279-T.Bis X X X X X X X X X
(-).0710.F1 X
(-).0710.B1 X
(-).1503.J XXX
4103-T.B X X
7001-T X X X X X
4202-T X X
NOTE: The oil pressure must be checked with the engine cold, after checking the oil level.
NOTE: The oil pressure warning lamp lights up at a threshold of 0.8 bar.
