303

CLUTCH

GEARBOX

DRIVESHAFTS

ML6 GEARBOX CONTROLS

Engine: RHR

Gear controls.

(1) Gear engagement ball-joint :Ø 10 mm

(2) Gear selection ball-joint :Ø 10 mm

(3) Gear engagement control cable

(4) Gear control lever

(5) Gear selection control cable

(6) Reverse gear unlocking cable

(7) O-ring seal

(8) Reverse gear unlocking device

B2CP3ZPD
