319
CLUTCH
GEARBOX
DRIVESHAFTS
DRIVESHAFT SPECIFICATIONS
Engines: KFU – NFU – RFN – RFJ – RFK – 9HX – 9HY– 9HZ – RHR
B2FP05CP
NOTE: The wheel hubs have a bearing with an integral magnetic wheel designed
for the ABS system.
Features.
The driveshafts no longer have crownwheels for the ABS system.
This function is assured by the wheel bearings.
The driveshaft gaiters are fixed by means of recessed ring seals.
In the event of the driveshafts being repaired, the recessed ring seals are replaced
by clips.
Tightening torques (m.daN).
Driveshaft nuts : 32,5 ± 2,6
Driveshaft bearings :2 ±0,2
