236
ENGINES
FILLING AND BLEEDING THE COOLING CIRCUIT
Tools.
[1] Filling cylinder :4520-T
[2] Adaptor for filling cylinder :4222-T
[3] Control rod for filling cylinder :4370-T
IMPERATIVE: Respect the safety and cleanliness requirements.
The draining and refilling operations can be carried out using coolant fluid
replacement equipment.
It is essential to follow the instructions as stated for that equipment.
Draining.
Remove the header tank cap.
Uncouple the radiator bottom hose.
Remove the drain screw from the cylinder block.
Filling and bleeding.
Open the bleed screws of the following components:
- Heater matrix outlet.
- Coolant outlet housing.
Connect the radiator bottom hose.
Fit the drain screw on the cylinder block (screw equipped with a new seal).
Tighten to 3 ± 0,3 m.daN.
B1GP00AC
Engines: KFU - NFU - RFJ - RFN - RFK - RHR
E5AP2CNC
E5AP1GNC
