235

ENGINES

VALVE CLEARANCE SETTINGS

The valve clearances must be checked with the engine cold

● Inlet

KFU

NFU

RFN RFJ RFK

9HX 9HY 9HZ RHR

Exhaust

Hydraulic adjustment

1 ± 0,05 mm

Rocking

Adjust

1 ● 1

3 ● 3

4 ● 4

2 ● 2

4 ● 4

2 ● 2

1 ● 1

3 ● 3

Inlet

●

Exhaust

Rocking

Valves

fully

open

Adjust

3 ● 4

4 ● 2

2 ● 1

1 ● 3

Fully open (Exhaust)

POSSIBLE PROCEDURES

For engines with 4 cylinders in a line (1-3-4-2)

Engines without hydraulic

adjustment: the clearance (J)

should be checked opposite the

cam.

B1DP13QC

Hydraulic adjustment

UK-C4-page131-237-2004 15/11/04 9:19 Page 235
