351

AXLES

SUSPENSION

STEERING

GENERAL SPECIFICATIONS: POWER-ASSISTED STEERING

Reference Description

Fixing of the fixed central controls steering wheel on the steering

column shaft

8 Steering column interface

9 Locking handle

10 Fixing of the steering cardan on the distributor valve stem

11 Steering column support

The steering column is in aluminium.

The adjustment of the steering column for height and reach is by means of the handle (9).

B3EP16PD

Steering column

UK-C4-page322-360-2004 15/11/04 9:07 Page 351
