388

AIR

CONDITIONING

C5HP1C6C

Pollen filter

Note: The pollen filter is located in the engine compartment

on the RH side.

Removing.

Remove:

- The plastic pins (1).

- The plastic cover (2).

- The flap (3).

- The pollen filter (4).

Refitting.

Proceed in reverse order.

SPECIAL FEATURES: AIR CONDITIONING SYSTEM (R 134.a)

C5HP1C5C

C5HP1C7C

UK-C4-page385-409-2004 15/11/04 9:13 Page 388
