CLUTCH SPECIFICATIONS

Engine type KFU NFU RFN RFJ RFK

Gearbox type MA5/L MA5/N AL4 BE4/5N AL4 BE4R/5S

Supplier SACHS VALEO VALEO VALEO

Mechanism / Type 200 MF 3850 200 CPX 3850 230 DNG 5100 230 DNG 5100

Clutch disc SAE 24/48-8Z 11 RX 11 R 14X 11 R 14X

Identification 22 4 4

of the springs (Orange) (Black) (Blue) (Blue)

Number of splines 18

Ø of lining. Ext/Int 200/134 200/137 228.6/155 228.6/155

Quality of lining F810 DS 810 DS 810 DS 810 DS

1.4i 16V 1.6i 16V 2.0i 16V 2.0i 2.0i 16V

Petrol

272

CLUTCH

GEARBOX

DRIVESHAFTS

UK-C4-page271-321-2004 15/11/04 9:15 Page 272
