InteliLite Global Guide

104

Ready Gen-set is ready to run.

Cooling Gen-set is cooling before stop.

EmergMan

EMERGENCY MAN (PAGE 452) gen-set operation.

Example: Used for bypass the controller and engine manual start.

Engine started conditions

Engine speed (RPM) > Starting RPM (page 166) or

Oil pressure > Starting Oil Pressure (page 167) or

D+ terminal active (reached 80% of supply voltage) for minimum 1s or

Generator voltage > 25% of Nominal Voltage Ph-N (page 158) or Nominal Voltage Ph-Ph (page 159) (any

phase)

Note: Any of these condition will disconnect starter of the engine, however for transition to next state RPM

needs to be higher than Starting RPM (page 166).

Engine running conditions

Engine speed (RPM) > Starting RPM (page 166) or

Oil pressure > Starting Oil Pressure (page 167) or

Generator voltage > 25% of Nominal Voltage Ph-N (page 158)

Still engine conditions

Engine speed (RPM) < Starting RPM (page 166) or

Oil pressure < Starting Oil Pressure (page 167) or

Generator voltage < 50V (any phase)

Note: When the engine was running before and all above conditions are fulfilled, additional 2s delay is

necessary to confirm “still engine”.

When any engine running conditions are appeared on still engine than the Wrn Stop Fail (page 576) is

activated with following delay:

for generator voltage from 10V to < 50% of nominal voltage, Wrn Stop Fail has delay 1s

for generator voltage > 50% of nominal voltage, Wrn Stop Fail has delay 200ms

Oil pressure > Starting Oil Pressure (page 167), Wrn Stop Fail has delay 1s

for detected RPM, there is no delay.

Stop engine conditions

If no engine running conditions are validated than the controller will wait extra 12s before leaving the Machine

state Stop and than it will release the STOP SOLENOID (PAGE 511) output.
