Service manual OEB/OES/OGB/OGS
5_00e Troubleshooting list_L 25/27 2013-01-30
Options for identifying faults in the Altivar 12 frequency converter
If error message E03.xxx is present on the combi steamer, this may mean that the frequency
converter has detected a fault with itself, with the fan motor or with the motor cable. The frequency
converter indicates a fault by a flashing error code in the display (41).
The cause of the fault must be rectified before the frequency converter is reset. All faults can
be reset by disconnecting the frequency converter from the power supply for two minutes and then
switching it back on. The display will show the message "rdY" if there are no other faults present.
The following table summarizes the indications given by the display of the frequency converter
(Altivar 12) when there is a fault but no error message:
Indication and function Possible cause Corrective action
No error message, malfunctioning
No display
Power supply disconnected
No mains voltage present
Check power supply to
frequency converter
Check mains voltage across the
terminals of the frequency converter
Display message not listed
in error description
Reference mode or Supervision mode is
selected
Press "ESC" until "rdY" appears in the
display
Display message not listed
in function description
bFr
Default motor frequency
Frequency converter does not have valid
parameters
Replace the frequency converter
The following table summarizes the error messages in the display of the frequency converter
(Altivar 12):
Error code Possible cause Corrective action
Error message, display flashing
CFF
Incorrect configuration
HM unit not configured correctly Replace the frequency converter
CrFI
Initial load
Fault in load relay controller
Switch frequency converter off
and back on again
Check power supply to frequency
converter
Check stability of mains supply
Replace the frequency converter
InFb
Fault in internal
temperature sensor
Temperature sensor in
frequency converter not working
Short-circuit or open-circuit in frequency
converter
Replace the frequency converter
InFE
Internal CPU
Fault in the internal microprocessor
Switch frequency converter off
and back on again
Replace the frequency converter
ObF
Excessive braking
Braking too strong or excessive load
Check mains voltage
20% maximum above the maximum
mains voltage during operation
OCF
Excess current
Inertia or load too high
Mechanical obstruction
Check the mechanical
operation
Check ground connection of frequency
converter, check motor cable and motor
insulation
