Convotherm OEB Series User Manual

Service Handbook OEB/OES/OGB/OGS
6.11 Condenser removal and installation
Check:
 Water doesn‘t drain out even though the water pipes are clear.
 Excess steam comes out from the steam outlet on top of the unit.
i
Information:
 A dirty condenser disrupts the steam control in the bypass and thereby can
cause poor cooking results and can damage the unit.
 The oven must be horizontally aligned using the adjustable feet!
Safety:
 Only use CONVOTHERM CONVOClean new or CONVOClean forte for
cleaning the oven drain, the demoisturizing tub and the condenser!
Attention! Observe cleaning instructions on the package!
 Only use CONVOTHERM CONVOCAL for descaling the oven drain, the
demoisturizing tub and the condenser!
Attention! Observe cleaning instructions on the package!
 When cleaning or descaling, observe the safety instructions on the labels and
the safety information for the cleaner and descaler. Make sure to use the
protective equipment provided with the unit!
 There is danger of low pressure damage when these service instructions are
not observed!
Instructions - Condenser removal:
 Remove the clap-out floor of the condenser 21. It is outside under the unit on
the bottom 20. Remove the 2 screws M5 22 (cross width SW 8 or phillips
screwdriver) on the motor side, clap the plate down and remove the complete
floor plate.
 Remove the left hanging shelf rack in the oven and the cover of the
demoisturizing tub 1.
 Remove in the connection area all connections from the condenser 7:
- breather pipe 17 open hose fitting 16
- condenser probe B3 8 with seal 9  unscrew it
- the angle hose connection 18 and insert nozzle 19 for cooling the condenser
unscrew them
-
bypass gauge pipe 13 with copper seal ring 14  unscrew it
- hose to the unit drip tray 11  cut out the cable binder 10 and pull out hose
(only on table units).
 Loosen the Stop nut M6 15 on the fastening bracket on the condenser with the
underlaying washer 3.
 Loosen the hexagon screw M6 2 with washer 3 in the oven and holder cross 4
and let the condenser 7 out from under.
 Lift the condenser 7 out of the fastening bracket in the connection area.
 On standing units, the condenser 7 can now be removed from underneath the
unit.
On table units, the unit must be slightly lifted on its side in order to pull the
condenser 7 out towards the front.
AS/11-2011 6_11e_Condenser removal and installation_b
Page 1 / 3
