Service Handbook OEB/OES/OGB/OGS
6.17 Inner and outer door replacement
Attention:
Scratches on the glass panel of the inner or outer door, present the danger of
breakage and need to be replaced!
Check:
 Scratches on the glass panel of the inner or outer door
 Glass panel breakage on the inner or outer door
i
Information:
 When the oven door is opened and the unit is hot, the inner door can bulge
approx. 1-2 cm towards the oven. This is a normal process because the inner
door has a floating assembly and thereby the thermal tension is diverted.
 The door hinges as well as the sliding surfaces of the disappearing door
should be regularly smeared with an odorless cooking oil or another approved
food grease
 Please make sure to tell your customers! 
Safety:
 Maintenance and repair work should only be performed on a cold unit.
 Do not open the inner door at temperatures of > 80°C.
6.17.1 Replacing the inner door on table units
Instructions – Removing the inner door on table units:
 Open the holding clamps 4 on the inner door and swing out the inner door 2.
 Remove the hinge safety 6 on the lower hinge 5.
 Lift out the inner door 2 first and then out from above and under the pins of
hinges 5.
Instructions – Assembling the inner door on table units:
 Place the inner door 2 above and under the pins of the hinges 5 and set in
place.
 Assemble the hinge safety 6.
 Swing the inner door 2 closed and clamp it onto the holding clamps 4.
AS/11-2011 6_17e_Inner and outer door replacement_b
Page 1 / 4
