D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
106
1. Select the e
ntry.
2. Click
.
3. Define the values.
4. Click
. The entry is updated, and the device is updated.
To delete a FDB table entry:
1. Select the entry.
2. Click
. The entry is deleted, and the device is updated.
Defining Multicast Forwarding
The Multicast Forwarding Page displays the ports and LAGs attached to the Multicast service group in the Ports and LAGs
tables. Ports can be added either to existing groups or to new Multicast service groups. The Multicast Forwarding Page
permits new
Multicast service groups to be created. The Multicast Forwarding Page also assigns ports to a specific
Multicast service addres
s group.
1. Click L2 Features > Forward & Filtering > Multicast Forwarding. The Multicast Forwarding Page opens:
Figure 0–25 Multicast Forwarding Page
The Multicast Forwarding Page contains the following fields:
Field Description
VID
Defines the VLAN ID
Multicast MAC Address
Defines the Multicast MAC address to which packets are forwarded.
Unit
Defines the unit number.

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
