DGS-3100 Series Gigabit Stackable Managed Switch User Manual
66
Defining Time Ranges
Time ranges may be used to define time-based ACLs and to configure time ranges for PoE port
settings. The Time Range Setting Page defines a time range. To define a time range:
1. Click Confi
guration > Time Range Setting. The Time Range Setting Page opens:
Figure 2-166 Time Range Setting Page
The Time Range Setting Page contains the following fields:
Field Description
Range Name
Defines the Time Range Name. Up to 32 time ranges can be defined.
Start Time (HH:MM)
Specifies the time at which the time-based feature is enabled. The field format is HH:MM.
The possible field values are:
HH: 00 – 23 (hours, in military format)
MM: 00 – 59 (minutes)
End Time (HH:MM)
Specifies the time at which the time-based feature is disabled. The field format is HH:MM.
The possible field values are:
HH: 00 – 23 (hours, in military format)
MM: 00 – 59 (minutes)
Weekdays
Specifies the weekdays for which the time range applies.
Select All Days
Specifies that the time range is applied daily.
2. Define the Range Name, Start Time and End Time fields.
3. To define the applicable days, check the specific Weekdays or check Select All Days.
4. Click
. The Time Range is defined.
To delete a Time Range entry:
1. Select the entry.
2. Click
. A confirmation window is displayed .
3. Click
. The entry is deleted.
To view or modify Time Range settings:
To Next Page
