D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
Viewing ARP Table
The Browse ARP Table Page provides information regarding ARP VLANs, including which IP address was mapped to what
MAC address. To view the ARP table:
1. Click Monitoring > Browse ARP Table. The Browse ARP Table Page opens:
Figure 6-9 Browse ARP Table Page
The Browse ARP Table Page contains the following fields:
Field Description
VLAN Name
Defines the VLAN for which the ARP mappings are defined.
IP Address
Defines the station IP address, which is associated with the MAC address.
Total Entries
Displays current ARP table entries, detailing the user defined interface name, IP address, MAC
address and type (dynamic or static) of each entry.
MAC Address
Displays the MAC address associated with the IP address..
Type
Indicates how the MAC was assigned. The possible values are:
– Dynamic — Indicates that the MAC address is dynamically created.
– Static — Indicates the MAC address is a static IP address.
2. Click . The table updates and displays the values required.
3. Click
to clear the Browse ARP Table Page.
181

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
