D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
Viewing Port Properties
The Port Description Page allows network managers provide a description of device ports. To define a port description:
1. Click Configuration > >Port Configuration > Port Description. The Port Description Page opens:
Figure 0-6 Port Description Page
The Port Description Page contains the following fields:
Field Description
Unit
Defines the stacking member for which the port settings are displayed.
From Port
Defines the port number from which the port parameters are configured.
To Port
Defines the port number to which the port parameters are configured.
Description
Defines a user-defined port description.
2. Define the Unit, From Port, To Port, and Description fields.
3. Click
.
The port description is saved, and the device is updated.
35

D-Link DGS-3100 SERIES Specifications

General

Brand	D-Link
Model	DGS-3100 SERIES
Category	Switch
Language	English
