DGS-3100 Series Gigabit Stackable Managed Switch User Manual
Figure 0-8 ACL Profile L3 IPv4 ACL ICMP Page
The ACL Profile L3 IPv4 ACL ICMP Page contains the following fields:
Field Description
ICMP Type
Sets the ICMP Type field as an essential field to match.
ICMP Code
Sets the ICMP code field as an essential field to match.
2. Select the ICMP Type and/or ICMP Code fields.
3. Click
. The ACL profile is added, and the device is updated.
IGMP Filtering
To define IGMP filtering, select the IGMP option.
To define L3 IPv4 IGMP ACL profile:
1. Select IGMP. The ACL Profile L3 IPv4 IGM
P Page updates as follows:
213
