D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
The LLDP Global Setting Page contains the following fields:
Field Descri
p
tion
LLDP Status
Specifies the LLDP status on the device. The possible field values are:
Enabled — Enables LLDP on the device.
Disabled — Disables LLDP on the device. This is the default.
LLDP Forward Status
Specifies the LLDP packet forwarding status when LLDP is disabled on the device.
The possible field values are:
Enabled — Enables LLDP packet forwarding on the device.
Disabled — Disables LLDP packet forwarding on the device.
Message TX Interval
Defines the LLDP message update transmission interval in seconds. The possible
field values are 5 – 32768 seconds. The default is 30 seconds.
Message TX Hold Multiplier
Configures the Time-To-Live (TTL) of an LLDP packet, which is the time interval
that a receiving device holds an LLDP packet before discarding it. The TTL is
defined as the Message TX Hold Multiplier times the Message TX Interval. The
possible field values are 2 – 10. The default is 4.
LLDP TX Delay
Defines the time delay in seconds between successive LLDP frame transmissions
initiated by value or status changes. The possible field values are 1 – 8192 seconds.
The default is 2 seconds.
LLDP Reinit Delay
Defines the time interval in seconds before reinitializing an LLDP transmission after
LLDP is disabled. The possible field values are 1 – 10 seconds. The default is 2
seconds.
2. To configure LLDP Global parameters, select Enabled in the LLDP Status field and click . LLDP
is enabled, and the device is updated.
3. To configure the LLDP packet forwarding status when LLDP is disabled, define the LLDP Forward Status field
and click
. The LLDP packet forwarding status is defined, and the device is updated.
4. To configure LLDP Global parameters when LLDP is enabled, define the Message TX Interval, Message TX Hold
Multiplier, LLDP TX Delay and LLDP Reinit Delay fields and click
. The LLDP packet forwarding
status is defined, and the device is updated.
Defining LLDP Port Settings
The LLDP Port Setting Page displays LLDP port information and contains parameters for configuring LLDP port settings.
1. Click L2 Features > LLDP > LLDP Port Setting. The LLDP Port Setting Page opens:
11
1
