DGS-3100 Series Gigabit Stackable Managed Switch User Manual
Figure 0–6 Add/Edit VLAN Information Page
The Add/Edit VLAN Information Page contains the following fields:
Field Description
VID
Defines the VLAN ID.
VLAN Name
Defines the user-defined VLAN name. The field ranges up to 32 characters.
Unit
Defines the stacking member for which the VLAN parameters are displayed.
Untag Port
Defines the interface is an untagged VLAN member. Packets forwarded by the interface are
untagged.
Tag Port
Defines the interface is a tagged member of a VLAN. All packets forwarded by the
interface are tagged. The packets contain VLAN information.
Forbidden Port
Defines the interface VLAN membership, even if GVRP indicates the port is to be added.
Not Member
Indicates that the interface is not a member of the VLAN.
Port Select All
Selects all ports and either untags, tags, excludes, or removes the VLAN membership.
3. Define the VID, VLAN Name, and port-related fields.
4. Select the Tagged, Untagged, and Forbidden ports.
5. Click
. The VLAN is saved, and the device is updated.
To modify a VLAN:
1. Click L2 Features > 802.1Q VLAN. The VLAN Configuration Page opens:
2. Select a VLAN in the
VLAN Table.
3. Click
. The configured VLAN parameters are displayed in the Add/Edit VLAN Information section.
4. Modify the VLAN parameters.
5. Click
. The VLAN information is modified, and the device is updated.
