Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Name
Description
[3]
24V Encoder 32/33
[4]
MCB 102
[5]
MCB 103
[6]
Virtual Master
[7]
Frequency Input 29
N O T I C E
This option is only available in FC 302.
[8]
Frequency Input 33
[11]
Local Bus Reference
Reference from terminals 68 and 69.
[12]
Preset Reference
[13]
24V Encoder 27/29
[14]
MCB 102 Absolute
[15]
MCO Encoder 1 X56
[16]
MCO Encoder 2 X55
[20]
Digital Potmeter
[21]
Analog Input X30/11
[22]
Analog Input X30/12
[29]
Analog Input X48/2
[37]
Analog Input X49/1
[38]
Analog Input X49/3
[39]
Analog Input X49/5
Parameter 3-19 Jog Speed [RPM]
Table 203: Parameter 3-19 Jog Speed [RPM]
3-19 Jog Speed [RPM]
Default value: Size related
Parameter type: Range, 0 - par. 4-13 RPM
Setup: All setups
Conversion index: 67
Data type: Uint16
Change during operation: True
Enter a value for the jog speed n
JOG
, which is a fixed output speed. The drive runs at this speed when the jog function is activated.
The maximum limit is defined in parameter 4-13 Motor Speed High Limit [RPM]. See also parameter 3-80 Jog/Homing Ramp Time.
AU275636650261en-000101 / 130R0334 | 135Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
