8.1.3 Mains Supply 3x525-600 V AC
P15K P18K P22K
High/Normal Load
1)
NO NO NO
Typical Shaft Output [HP/kW] 25/18.5 30/22 40/30
Enclosure IP21, IP55, IP66 B1 B2 B2
Enclosure IP20 B3 B4 B4
Output current
Continuous
(3 x 525-550 V ) [A]
28 36 43
Intermittent
(3 x 525-550 V ) [A]
31 40 47
Continuous
(3 x 525-600 V ) [A]
27 34 41
Intermittent
(3 x 525-600 V ) [A]
30 37 45
Continuous kVA (550 V AC) [kVA] 26.7 34.3 41.0
Continuous kVA (575 V AC) [kVA] 26.9 33.9 40.8
Max. input current
Continuous
at 550 V [A]
25.4 32.7 39
Intermittent
at 550 V [A]
28 36 43
Continuous
at 575 V [A]
24 31 37
Intermittent
at 575 V [A]
27 34 41
Additional specications
IP21, IP55, IP66 max. cable cross-section
5)
(mains, brake, load sharing)
[mm
2
(AWG)]
2)
16, 10, 10 (6, 8, 8) 35,-,-(2,-,-) 35,-,-(2,-,-)
IP21, IP55, IP66 max. cable cross-section
5)
(motor) [mm
2
(AWG)]
2)
10, 10,- (8, 8,-) 35, 25, 25 (2, 4, 4) 35, 25, 25 (2, 4, 4)
IP20 max. cable cross-section
5)
(mains, brake, motor and load sharing)
10, 10,- (8, 8,-) 35,-,-(2,-,-) 35,-,-(2,-,-)
Estimated power loss
at rated max. load [W]
4)
285 329 700
Weight, enclosure IP21, IP55, IP66 [lbs/kg] 50.4/23 59.5/27 59.5/27
Weight, enclosure IP20 [lbs/kg] 26.46/12 51.8/23.5 51.8/23.5
Eciency
4)
0.98 0.98 0.98
Table 8.3 Mains Supply 3x525-600 V AC
