13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] OK key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Timeout 3
[71] SL Timeout 4
[72] SL Timeout 5
[73] SL Timeout 6
[74] SL Timeout 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning Selectable if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 164 ATEX ETR
cur.lim.alarm is active, the output
will be 1.
[91] ATEX ETR cur. alarm Selectable ifparameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 166 ATEX ETR
freq.lim.alarm is active, the output
will be 1.
[92] ATEX ETR freq. warning Selectable if parameter 1-90 Motor
Thermal Protection is set to [20]
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
ATEX ETR or [21] Advanced ETR. If
the alarm 163 ATEX ETR
cur.lim.warning is active, the
output will be 1.
[93] ATEX ETR freq. alarm Selectable if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the warning 165 ATEX ETR
freq.lim.warning is active, the
output will be 1.
[94] RS Flipop 0 See 13-1* Comparators
[95] RS Flipop 1 See 13-1* Comparators
[96] RS Flipop 2 See 13-1* Comparators
[97] RS Flipop 3 See 13-1* Comparators
[98] RS Flipop 4 See 13-1* Comparators
[99] RS Flipop 5 See 13-1* Comparators
[100] RS Flipop 6 See 13-1* Comparators
[101] RS Flipop 7 See 13-1* Comparators
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the rst logical operator to use on the
Boolean inputs from parameter 13-40 Logic
Rule Boolean 1 and parameter 13-42 Logic Rule
Boolean 2.
[13-**] signies the boolean input of
parameter group 13-** Smart Logic Control.
[0] DISABLED Ignores parameter 13-42 Logic Rule Boolean 2,
parameter 13-43 Logic Rule Operator 2, and
parameter 13-44 Logic Rule Boolean 3.
[1] AND Evaluates the expression [13-40] AND [13-42].
[2] OR Evaluates the expression [13-40] OR [13-42].
[3] AND NOT Evaluates the expression [13-40] AND NOT
[13-42].
[4] OR NOT Evaluates the expression [13-40] OR NOT
[13-42].
[5] NOT AND Evaluates the expression NOT [13-40] AND
[13-42].
[6] NOT OR Evaluates the expression NOT [13-40] OR
[13-42].
[7] NOT AND
NOT
Evaluates the expression NOT [13-40] AND
NOT [13-42].
Parameter Descriptions Operating Instructions
MG34M422 Danfoss A/S © Rev. 2013-07-03 All rights reserved. 95
