Danfoss VLT CDS 303 User Manual

0-20 Display Line 1.1 Small
Option: Function:
[1673] Counter B
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[2580] Cascade Status
[2581] Compressor Status
[2587] Inverse Interlock
[2827] Discharge Temperature
[9913] Idle time
[9914] Paramdb requests in queue
[9917] tCon1 time
[9918] tCon2 time
[9919] Time Optimize Measure
0-25 My Personal Menu
Range: Function:
Size
related*
[0 -
9999 ]
Dene up to 20 parameters to include in
the Q1 Personal Menu, accessible via the
[Quick Menu] key on the LCP. The
parameters will be displayed in the Q1
Personal Menu in the order they are
programmed into this array parameter.
Delete parameters by setting the value to
« 0000 ».
0-21 Display Line 1.2 Small
Option: Function:
Options are the same as in
parameter 0-20 Display Line 1.1 Small
[1614] * Motor Current
[A]
0-22 Display Line 1.3 Small
Option: Function:
Options are the same as in
parameter 0-20 Display Line 1.1 Small.
[1610] * Power [kW]
0-23 Display Line 2 Large
Option: Function:
Options are the same as in
parameter 0-20 Display Line 1.1 Small.
[1613] * Frequency [Hz]
0-24 Display Line 3 Large
Option: Function:
Options are the same as in
parameter 0-20 Display Line 1.1 Small.
[1662] * Analog Input
53
0-30 Unit for User-dened Readout
Option: Function:
It is possible to program a value to be
shown in the display of the LCP. The value
will have a linear, squared or cubed relation
to speed. This relation will depend on the
unit selected (see ). The actual calculated
value can be read in parameter 16-09 Custom
Readout, and/or shown in the display be
selecting [16-09] Custom Readout in
parameter 0-20 Display Line 1.1 Small to
parameter 0-24 Display Line 3 Large.
[0] None
[1] %
[5] PPM
[10] min
[11] RPM
[12] PULSE/s
[20] liter / sec.
[21] liter / min
[22] liter / hr.
[23] m³ / sec.
[24] m³/min
[25] m³ / hr.
[30] kg / sec.
[31] kg/min
[32] kg / hr.
[33] ton / min
[34] ton / hr.
[40] m / sec.
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal / sec.
[122] gal/min
[123] gal / hr.
[124] CFM
[125] ft³/s
Parameter Descriptions
VLT
®
Compressor Drives CDS 302/CDS 303
50 Danfoss A/S © Rev. 2013-07-03 All rights reserved. MG34M422
6
6
