13-01 Start Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option: Function:
[47] Up key
[
▲
] is pressed.
[48] Down key
[
▼
] is pressed.
[50] Comparator 4 Use the result of comparator 4.
[51] Comparator 5 Use the result of comparator 5.
[60] Logic rule 4 Use the result of logic rule 4.
[61] Logic rule 5 Use the result of logic rule 5.
[94] RS Flipop 0 See parameter group 13-1* Comparators
[95] RS Flipop 1 See parameter group 13-1* Comparators
[96] RS Flipop 2 See parameter group 13-1* Comparators
[97] RS Flipop 3 See parameter group 13-1* Comparators
[98] RS Flipop 4 See parameter group 13-1* Comparators
[99] RS Flipop 5 See parameter group 13-1* Comparators
[100] RS Flipop 6 See parameter group 13-1* Comparators
[101] RS Flipop 7 See parameter group 13-1* Comparators
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to deactivate Smart
Logic Control.
Option: Function:
[0] FALSE For descriptions [0]-[61], see
parameter 13-01 Start Event Start
Event
[1] TRUE
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reverse
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to deactivate Smart
Logic Control.
Option: Function:
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Timeout 0
[31] SL Timeout 1
[32] SL Timeout 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] OK key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Timeout 3 Smart Logic Controller timer 3 is
timed out.
[71] SL Timeout 4 Smart Logic Controller timer 4 is
timed out.
[72] SL Timeout 5 Smart Logic Controller timer 5 is
timed out.
[73] SL Timeout 6 Smart Logic Controller timer 6 is
timed out.
[74] SL Timeout 7 Smart Logic Controller timer 7 is
timed out.
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
Parameter Descriptions Operating Instructions
MG34M422 Danfoss A/S © Rev. 2013-07-03 All rights reserved. 87
