Loading an Ink Ribbon

Ifthisisthefirsttimeyouareusingtheprinter,powerontheprinteruntilaninkerrororafilm

erroroccurs,thenpoweritoff.(Theprinterisshippedintransportmode,whichdoesnotallow

inkribbonorretransfermaterialtobeinstalled.Poweroncancelstransport

mode.)

1. Slidethedoorlatchupandopentheprinterdoor.

2. Pre sstheinkribbonreleasebuttonandremovethe

orangecartridge.

3. Removebothusedribbonspoolsfromthecartridge(if

present).

4. Loadthenewrollofinkribbononthecartridge:

a. Putthefullspoolofribbononthe

orangesupply

spindle(A).

b. Puttheemptytak e‐upspoolontheblacktake‐up

spindle(B).

c. Alignribbonalongthethreeribbonguides(C).

d. Makesurethattheribbonpanelsmatchthecolored

diagraminthecartridge(D).

e. Takeupanyslackbyturningthesupplyknobcounter‐

clockwise.Gently

pullthetake‐upknobandturn(E).If

slackcannotberemoved,verifythatthesupplyandtake‐

upspoolsarefirmlyseatedonthespindles.

Toeaseinsertingintotheprinter,thefilmmustbe

tightalongtheribbonguides.Turningthesupplyand

take‐upknobshelps

maintainthepropertension.

5. Replacetheloadedribboncartridgeintheprinteruntilit

clicksintoposition.

6. Closetheprinterdoor.
