Datalogic PowerScan PM9500 User Manual

2D Global Features Enter/Exit Programming Mode
Product Reference Guide 183
Data Matrix DPM Decoding Safety
This feature defines the tolerance of DPM decoding software to operate with
poor quality labels. Decoding Safety is used to configure a barcode symbol-
ogy decoder to be very aggres
sive to very conservative depending on a par-
ticular customer’s needs. Higher tolerance to poor quality labels increases
the reading capability of
the scanner.
See
page 267 for more information on this feature.
DEFAULT
$CDMDA01(CR)
Data Matrix Decoding Safety = 1 (Aggressive)
$CDMDA02(CR)
Data Matrix Decoding Safety = 2
$CDMDA03(CR)
Data Matrix Decoding Safety = 3
$CDMDA04(CR)
Data Matrix Decoding Safety = 4
$CDMDA05(CR)
Data Matrix Decoding Safety = 5 (Conservative)
This feature is valid for the PD9530-DPM model only.

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
