Datalogic PowerScan PM9500 User Manual

Enter/Exit Programming Mode
Product Reference Guide 237
Changing System Speed
1. Link the PM9500 with a BC9xxx Base.
2. With the PM9500, read a “Compatib
le Mode/Normal Mode Speed” pro-
gramming label on
page 238 to set “Low, Medium, or High Speed”.
3. Place the PM9500 into the BC9xxx.
The Reader and Base will now be linked at the new programmed speed.
This feature can also be progra
mmed using Datalogic Aladdin.
1. On the BC9xxx Base, change the Compatible mode
parameter to low,
intermediate, or high speed through Aladdin.
2. Place an unlinked PM9500 onto the BC9xxx base.
The Reader and base will link at the new programmed speed.

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
