Datalogic PowerScan PM9500 User Manual

LED and Beeper Indications
Product Reference Guide 303
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indicate various func-
tions or errors on the reader. An optional “Green Spot” also performs useful
fun
ctions. The tables below list these indications. One exception to the
behaviors listed in the tables is that the reader’s functions are programma-
ble, and may or may not be turned on. For example, certain indications such
as the power-up
beep can be disabled us
ing programming bar code labels.
Table 53.
INDICATION DESCRIPTION LED BEEPER
Power-up
Beep
The reader is in the pro-
cess of powering-up.
Reader beeps four
times
at highest fre-
quency and volume
upon power-up.
Good Read
Beep
A label has been suc-
cessfully scanned by
the r
eader.
LED behavior for
this in
dication is
configurable via
the feature “
Good
Read: When to
Indicate
”
The reader will beep
once at
current fre-
q
uency, volume, tonal
sett
ing and duration
upon a successful label
scan.
Green Spot
a
a. Except when in sleep mode or when a Good Read LED Duration other than 00 is selected
flashes
mome
ntarily
Upon successful read of
a labe
l, the software
turns the green spot on
for the time specified by
the configured value.
N/A N/A
Image Cap-
ture
When ready to capture
Blue light flashes 2
times when updat-
in
g
N/A
LED and Beeper Indications
Table 54. Programming Mode Indications
Programming Mode - The following indications ONLY occur when the reader is in Pro-
gramming Mode.
INDICATION DESCRIPTION LED BEEPER
Label Program-
ming Mode Entry
A valid programming
label has been scanned.
LED blinks con-
tinuously
Reader sounds
four low frequency
beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been rejected. N/A
Reader sounds
t
h
ree times at low-
est frequency &
current volum
e.
Label Program-
ming Mode Accep-
tance of Partial
Label
In
cases where multiple
labels must be
scanned
to program
one feature,
this indication acknowl-
edges each portion as it is
success
fully scanned.
N/A
Reader sounds one
short beep at high-
est frequency &
current volum
e.

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
