Datalogic PowerScan PM9500 User Manual

Enter/Exit Programming Mode
Product Reference Guide 229
Bluetooth HID Alt Mode
Enable/Disable the ability to correctly transmit a label to the host regardless
of the Bluetooth HID Country Mode selected, when Bluetooth HID Profile is
configured.
Read the configuration command label belo
w for the HID Alt Mode feature.
HID Alt Mode = OFF
DEFAULTDEFAULT
HID Alt Mode = ON
Bluetooth HID Send Unknown ASCII Char
Unknown characters are characters the host does not recognize. When Dis-
able HID Send ASCII Unknown character is selected, all barcode data is sent
ex
cept for unknown characters, and an error beep will sound. When
HID
Send Unknown ASCII character
is enabled, an unknown character will be
sent as a SPACE.
DEFAULT
$CBTHO00(CR
HID Send Unknown ASCII character = Disable
CBTHO01(CR
HID Send Unknown ASCII character = Enable

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
