Appendix A
Technical Specifications
The tables that follow contain Physical and Performance Characteristics,
User Environment and Regulatory information.
Table 52 provides Standard
Cable Pinouts.
Table 51. Technical Specifications
Item Description
Physical Characteristics
Dimensions
Height: 212 mm
Length: 110 mm
Width: 74 mm
Weight (without cable) 330 gr (without cable)
Electrical Characteristics
PD9530 models
Voltage & Current
PD9530/
PD9530-HP
PD9530-HPE PD9530-DPM
Input Voltage 5 VDC +/- 5% 10 to 30 VDC 5 VDC +/- 5%
Input Current
Operating (typical): 335mA 135mA @ 10V 350mA
Operating (max): 475mA 300mA @ 10V 480mA
Idle/Standby (typical) 180mA 60mA @ 10V 120mA
PBT9500 and PM9500 models
Battery Type Li-Ion battery pack
Charge time for full
charge fro
m full dis-
charge
4 hours with external power supply adapter
a
a. Charge Times are much lower when battery is within daily typical operating condition.
Typical 10 hours with Host power (in this case no supply
adapter is needed)
a
Operating autonomy
(continuous reading)
30,000 reads (typical)
Cradle consumption and
DC in
put supply range
Volt 10-30 VDC; Power <8W
b
b. Typical input current measured under factory default configuration.
;
Max 500mA when in host/bus powered mode
b
.

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
