Datalogic PowerScan PM9500 User Manual

Setup
14 PowerScan™ PD9530/PBT9500/PM9500
BC9xx0 Configuration
The BC9xx0 configuration can be performed in three ways: by using the
Datalogic Aladdin
™
software configuration program, by sending configura-
tion strings from the Host PC via the RS-232 or USB-COM interface or by
re
ading configuration bar codes with the PowerScan
™
9500 reader.
Serial Configuration
By connecting the BC9xx0 to a PC through an RS-232 or USB-COM interface
cable it is possible to send configuration strings from the PC to BC9xx0.
Configuration Bar Codes
Link the cradle and the reader using the procedures described in the Power-
Scan
™
PM9500 or PBT9500 Quick Reference. Once the pairing is complete,
you can configure the BC9xx0 cradle by reading configuration bar codes in
this manual.
To configure the BC9xx0 using the PowerScan
™
9500 reader (paired to the
cradle with the Bind command), follow the procedure according to the inter-
face selected.
Interface Selection
Upon completing the physical connection between the reader and its host,
proceed to
Table 2 on page 15 to select the interface type the reader is con-
nected to (for example: RS-232, Keyboard Wedge, USB, etc.). Scan the
appropriate bar
code in that s
ection to configure your system’s correct
interface type.
Setting the Interface
Scan the programming bar code from this section which selects the appro-
priate interface type matching the system the reader will be connected to.
Ne
xt, proceed to the corresponding section in this manual (also listed in
Table 2 on page 15) to configure any desired settings and fea
t
ures associ-
ated with that interface.
Unlike some programming features and options, interface selections
require that you scan only one programming bar code label. DO NOT scan an
ENTER/EXIT bar code prior to scanning an interface selection bar code.
Some interfaces require the scanner to start in the disabled state when
powered up. If additional scanner configuration is desired while in this
state, pull the trigger and hold it for five seconds. The scanner will change to
a state that allows programming with bar codes.

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
