Datalogic PowerScan PM9500 User Manual

Enter/Exit Programming Mode
248 PowerScan™ PD9530/PBT9500/PM9500
Enable/disable buttons
This feature offers the ability to enable or disable each key independently.
Figure 6. PowerScan 9500 Keypad
Key Programming .
$CPWFZF000\r
All 4 keys enabled
DEFAULT
$CPWFZ0000\r
All 4 keys disabled
$CPWFZ
Enable a combination of the 4 keys
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code
at
left followed by 4 digits from the Alphanumeric
characters in
Appendix D, Keypad .
The last 3 digits must always be 0; the 4 bits of the
firs
t digit must be 1 if the corresponding key is
enabled; the four bits represent, starting from the
highest: Arrow Up, F2, F1, Arrow Down. End by scan-
ning the ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to
abort
and not save the entry string. You can then start
again at the beginning.
~
CANCEL

Datalogic PowerScan PM9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	-
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Wireless range	150 m
Operating frequency	910 MHz
Standard interfaces	USB, RS-232, RS-485
Connectivity technology	Wireless
Certification	IEC 60825 Class 2 IEC 62471 Class 1 LED
Product color	Black, Yellow
LED indicators	Yes
Protection features	Shock resistant
International Protection (IP) code	IP65
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Battery life	10 h
Charging time	4 h
Input voltage	12 V
Battery capacity	2150 mAh
Power consumption	150 mA
Power source type	Battery
Cables included	No

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
