Configuring OSPF and OSPFv3 953

Table 35-2 shows the per-interface default values for OSPF and OSPFv3.

Table 35-2. OSPF Per-Interface Defaults

Parameter Default Value

Admin Mode Disabled

Advertise Secondaries Enabled (OSPFv2 only)

Router Priority 1

Retransmit Interval 5 seconds

Hello Interval 10 seconds

Dead Interval 40 seconds

LSA Ack Interval 1 second

Interface Delay Interval 1 second

MTU Ignore Disabled

Passive Mode Disabled

Network Type Broadcast

Authentication Type None (OSPFv2 only)

Metric Cost Not configured
