1.3 Servo Drive and Corresponding Servo Motor
ASDA-M Series Servo Drive
Servo Drive Corresponding Servo Motor
750W ASD-M-0721-
ECMA-C1040FS（S=8 mm）
ECMA-C
△0401S（S=8 mm）
ECMA-C
△0602S（S=14 mm）
ECMA-C
△0604S（S=14 mm）
ECMA-C△0604H ( H = high-inertia)
ECMA-C
△08047（7=14 mm）
ECMA-C
△0807S（S=19 mm）
ECMA-C△0807H ( H=high-inertia)
ECMA-C
△0907S（S=16 mm）
ECMA-E
△1305S（S=22 mm）
ECMA-G
△1303S（S=22 mm）
ECMA-G
△1306S（S=22 mm）
1500W ASD-M-1521-
ECMA-C△0807S（S=19 mm）
ECMA-C△0807H ( H=high-inertia)
ECMA-C
△0907S（S=16 mm）
ECMA-C
△0910S（S=16 mm）
ECMA-C
△1010S（S=22 mm）
ECMA-E
△1310S（S=22 mm）
ECMA-F△1308S（S=22 mm）
ECMA-F△1313S（S=22 mm）
ECMA-E△1315S（S=22 mm）
ECMA-G
△1309S（S=22 mm）
NOTE
1) Box, () at the end of the model name of the servo drive represents the code of
ASDA-M. Please refer to the type of purchasing product information.
2) Triangle, (△) in the mode name of the servo motor represents the type of encoder.
△=1: incremental, 20-bit；△=2: incremental, 17-bit; △=3: 2500 ppr; △=A: Absolute.
The listed model name is for reference. To purchase the product, please contact the
local dealer for product availability.
3) Box, () in the model name of the servo motor represents the type of brake or
keyway / oil seal.
The above table shows the specification of servo drive which has triple rated current. If the
user needs the servo drive which has six times of the rated current, please contact with
distributors. For detailed specification of the servo motor and servo drive, please refer to
the appendix.
